JY-872 Bremslichtkamera für 2001-2011 Opel Combo, 2001-2014 Vauxhall Vivaro, 2001-2013 Renault Traffic
Produktmerkmale
The Luview JY-872 brake light camera is revolutionizing the way we travel in vehicles. Not only does it provide an extra layer of safety, but also a sleek and stylish complement to any 2001-2011 Opel Combo, 2001-2014 Vauxhall Vivaro or 2001–2013 Renault Traffic design style. Connecting this innovative device directly to your monitor allows you to visually display stunning images when reversing – giving you greater security as well peace of mind while on the road!
- Wasserdicht nach IP69K
- Mit Nachtsichtfunktion
- unterstützt analoges HD-Video 700TVL
- Unterstützung von Spiegelschalt- und Linealsteuerungsfunktionen
Technische Daten
| Bildsensor | 1/3 CMOS PC1058K |
| TV-System | NTSC/PAL |
| Effektive Pixel | 976(H)×592(V) |
| Erfassungsbereich | 4.880mmⅹ 3.670mm |
| Übersetzen. System | Intern |
| Auflösung | 700TVL |
| Minimale Beleuchtungsstärke | 0,1 Lux (Tag), 0 Lux (mit IR) |
| Mikrofon | Optional |
| IR-LED-Anzahl | 2PCS |
| Video-Ausgang | 1,0 Vp-p/75 Ohm |
| Scannendes System | verschachtelt |
| AGC | AUTO |
| Signal-Rausch-Verhältnis | Besser als 48 dB |
| Weißabgleich | AUTO |
| Gamma-Verbrauch | 0.45 |
| Elektronischer Verschluss | AUTO |
| Gegenlicht-Kompensation | AUTO |
| Stromversorgung | DC12V |
| Objektiv | 1,7 mm |
| Winkel des Objektivs | 145° |
| Stromabfluss | Stromstärke bei Tag 50mA ± 5, Stromstärke bei Nachtsicht 210mA ± 5 |
| Betriebstemperatur | -20℃-70℃,RH 95% MAX |
| Lagertemperatur | -30℃-80℃,RH 95% MAX |
