5 Inch IP68 Waterproof 2.4GHZ Digital Wireless HD Backup Camera System

Product Features

2.4G digital wireless connection, easy installation without wiring. Small mini body, do not block the line of sight, driving safety is guaranteed. With a special sunction cup bracket to stick firmly so that it will not fall off.

  • Waterproof IP68
  • Fast switching speed of up to 150 milliseconds
  • 12-32V
  • Support 2 cameras input
  • Strong suction cup for secure mounting and easy installation

System Includes

  1. 5 inch wireless monitor
  2. Wireless camera
  3. 5 meters DC extension cable
  4. Cigarette lighter

Technical Specifications

LCD size 5"
Resolution 800*3 (RGB)*480
Contrast 1500:1
Brightness 500cd/㎡
Pixel Pitch 45um(H) x 135um(V)
Aspect Ratio 5:3
Channel 2 channels
Operating Frequency 2412 - 2483.5 MHz
Receiving Sensitivity 11Mbps-86dBm@8%
Decompression Form MPEG4
Transmit Output Power 20dBm@11b MAX
Modulation OFDM
Time Delay 150ms Max
Transmitting Distance 80-130 Meters
Power Supply DC8-32V
Power Consumption Max. 5W
Operating Temperature -20℃ to +70℃ , RH90%
Storage Temperature -30℃ to +80℃ , RH90%
Image Sensor 1/3 CMOS
View Angle 156°(D) 133°(H) 73°(V) (Camera)
IP Protection IP68 (Camera)
