7″ Four Channel Flip Down Car Monitor Wireless Car Camera System
Product Features
The Luview JY-M745W + JY-6731W 7 inch LCD monitor and ip69K waterproof car camera system is the perfect way to easily access wireless video messages. Its sturdy construction and clear picture make it ideal for any vehicle – from cars, trucks and lorries to excavators – as a convenient reversing imaging system when paired with a quality wireless backup camera.
1.Multi-languages of display available:English, Dutch, French, Portuguese, Spanish, Italian, Swedish, German, Chinese
2.With remote control function
3.The monitor has speakers that can adjust the sound from the control panel or remote control
4.Supporting simultaneous video input from four cameras can support 2 segmentation and 4 segmentation
5.Supporting simultaneous audio input from four cameras (optional)
6.Images can be flipped up and down from left to right
7.4-way trigger control line, automatic switching when triggered
8.In standby mode, it will start up automatically when triggered and switch to the corresponding camera image
9.The working power supply range is 12~24V, with short circuit protection function of power supply
Technical Specifications
Screen Size | 7"/16:9 | ||||
Resolution | 800(W)* R.G.B * 480(H) | ||||
TV System | PAL/NTSC | ||||
Brightness | 300cd/m² | ||||
Contrast | 500:1 | ||||
Active Area | 154.08(W) × 85.92(H) mm | ||||
Viewing Angle | U/D:50°/70°,R/L:70°/70° | ||||
Image Settings | Brightness,Color,Contrast | ||||
Video Format | CVBS | ||||
Mirror Flip | Non-mirror, mirror, flip, mirror flip | ||||
Video Channel | Four channel video input, four audio optional | ||||
Reverse Function | Four way back (ruler setting function) | ||||
Reversing Delayed | 0-15s | ||||
Scale Function | 4-way ruler, automatic switching of ruler | ||||
Power Supply | 12/24V,DC/<9W | ||||
Operating Temperature | -20℃ to +65℃ | ||||
Storage Temperature | -25℃ to +70℃ |
