JY-684-5 third brake light camera for 2003-2022 Chevy Express & GMC Savana Cargo Van
Product Features
The Luview JY-684-5 third brake light camera offers ultimate visibility when it comes to backing up your 2003-2022 Chevy Express or GMC Savana Cargo Van. This handy device lets you see all that lies behind, even in low lighting conditions – with an adjustable lens angle and IP68 waterproof rate for clear images no matter what the circumstances! With excellent night vision capabilities and a wide viewing angle, drivers can always have peace of mind knowing they have a dependable way to back out easily and safely.
- IP68
- Support mirror switch
- bracket material:plastic
- Supporting ICR switching
- High performance 2Megapixel sensor of SONY
- With night vision function, infrared distance is 10m
Technical Specifications
| Image Sensor | 1/3 CMOS PC1099K |
| TV System | NTSC/PAL |
| Effective Pixels | 968(H)×488(V) |
| Sensing Area | 4.880mmⅹ 3.670mm |
| Sync. System | Internal |
| Resolution | 700TVL |
| Minimum Illumination | 0.1 Lux (day), 0 Lux (with IR) |
| Microphone | Optional |
| IR LED Qty | 6PCS |
| Video Output | 1.0 Vp-p/75 Ohm |
| Scanning System | interlace |
| AGC | AUTO |
| Signal to noise ratio | Better than 48dB |
| White balance | AUTO |
| Gamma Consumption | 0.45 |
| Electronic Shutter | AUTO |
| Backlight Compensation | AUTO |
| Power Supply | DC12V |
| Lens | 2.6mm |
| Lens Angle | 130° |
| Current Drain | 65±5mA |
| Operating Temperature | -20℃-70℃,RH 95% MAX |
| Storage Temperature | -30℃-80℃,RH 95% MAX |
