JY-660 IP69K side view camera with HD 2 mega pixel Sony sensor
Product Features
JY-660 is a high-definition universal reversing side view camera, which is waterproof and used for large cars. Using this camera, the driver can easily reversing by himself, and can avoid the danger caused by visual blind spots and the damage caused by turning. The lens of this camera has do the strict high and low temperature tests so it is stable;
Camera smart chip has clear and delicate image, supports analog high-definition video 700TVL, clear night vision, and infrared distance 13 meters.
As a professional truck safety system manufacturer and supplier in China, LUVIEW can provide you with a variety of high-definition rear-view truck cameras, RV rear-view cameras, reversing trailer cameras, bus cameras, etc.
- IP69K
- Support mirror switch
- Support ICR switching
- Infrared distance is 13m
- 2 Mega pixel sensor of SONY
- With night vision function
Technical Specifications
| Image Sensor | 1/3 AHD |
| TV System | NTSC/PAL |
| Effective Pixels | 1280(H)×960(V) |
| Sensing Area | 3.75μm |
| Sync. System | Internal |
| Resolution | 1.3 mega pixels |
| Minimum Illumination | 0.1 Lux (day), 0 Lux (with IR) |
| Microphone | Optional |
| IR LED Qty | 8PCS |
| Video Output | 1.0 Vp-p/75 Ohm |
| Scanning System | interlace |
| AGC | AUTO |
| Signal to noise ratio | Better than 48dB |
| White balance | AUTO |
| Gamma Consumption | 0.45 |
| Electronic Shutter | AUTO |
| Backlight Compensation | AUTO |
| Power Supply | DC12V |
| Lens | 2.8mm |
| Lens Angle | 102° |
| Current Drain | 70±5mA |
| Operating Temperature | -20℃-70℃,RH 95% MAX |
| Storage Temperature | -30℃-80℃,RH 95% MAX |
