JY-669 DC12V IP68 700 TVL side view camera with CMOS image sensor

Traveling with your RV and motorhome can be an amazing experience while maneuvering it was not, especially when you are crossing the street with kids around. Luview special designed RV, motorhome side view backup camera will help you back a large vehicle easily without any blind spot, day and night, especially when the two side view backup cameras were using together with a rear view camera, they will save life and your time. Luview RV, motorhome side view backup camera features IP68 water proof grade and maximum 700 TV lines high resolution, night vision distance up to 35 ft, you can always reply on them. If you are looking to import backup side view camera for rv, motorhome, fifth wheel trailer, travel trailer, toy hauler, truck camper; please don’t hesitate to contact: [email protected]

Product Features

Accessories such as bend brackets and tray mounting brackets for choosing, these accessories can be adjusted to an angle of +90° for flexible installation in a variety of installation environments.

  • Use 1/3 CMOS sensor, support analog hd video 700 TVL
  • Waterproof grade IP68
  • Support mirror switch and scale control function
  • With night vision function, infrared distance is 10 meters
  • It can be mounted on both sides of the vehicle

Technical Specifications

Image Sensor 1/3 CMOS PC2099K
TV System NTSC/PAL
Effective Pixels 968(H)×488(V)
Sensing Area 4.880mm*3.670mm
Sync. System Internal
Resolution 700TVL
Minimum Illumination 0.1 Lux (day), 0 Lux (with IR)
Microphone NO
IR LED Qty 9PCS
Video Output 1.0 Vp-p/75 Ohm
Scanning System interlace
AGC AUTO
Signal to noise ratio Better than 48dB
White balance AUTO
Gamma Consumption 0.45
Electronic Shutter AUTO
Backlight Compensation AUTO
Power Supply DC12V
Lens 2.8mm
Lens Angle 115°
Current Drain 65±5mA
Operating Temperature -20℃-70℃,RH 95% MAX
Storage Temperature -30℃-80℃,RH 95% MAX
