JY-MR07 7 inch HD lcd rearview mirror monitor with speaker
Product Features
JY-MR07 is a rearview mirror monitor, with remote control function, use and installation process is flexible and convenient. The display supports two video input and one audio input. The second camera has a trigger control line, when there is a trigger, automatic switch. In standby state, it will automatically start up when triggered, and switch to the corresponding camera image. The display quality is clear and delicate, the color is realistic, the image can be flipped freely up and down, easy to view.
- Display with speaker
- With remote control function
- Supporting simultaneous audio input from one camera (optional)
- Supports video input from two cameras at the same time
- Images can be flipped up and down from left to right
- With short circuit protection function of power supply
Technical Specifications
| Screen Size | 7"/16：9 |
| Resolution | 800（W）* R.G.B * 480(H) |
| TV System | PAL/NTSC/AUTO |
| Brightness | 300cd/㎡ |
| Contrast | 500:1 |
| Active Area | 154.08(W) × 85.92(H) mm |
| Viewing Angle | U/D:70°/70°,R/L:50°/70° |
| Image Settings | Brightness、Color、Contrast |
| Video Format | CVBS |
| Mirror Flip | Non-mirror, mirror, flip, mirror flip |
| Video Channel | Two channel video input |
| Reverse Function | Single way back (ruler setting function) |
| Reversing Delayed | 0-15s |
| Scale Function | Two scale ruler and automatic ruler switch |
| Power Supply | 12/24V，DC/<9W |
| Operating Temperature | -20℃ to +65℃ |
| Storage Temperature | -25℃ to +70℃ |
